The Belltec H-200 Heavy Duty Auger Drive is built for professional drilling applications that demand strength, versatility, and dependable hydraulic performance. Designed for machines producing 10–20 GPM, the H-200 develops up to 2,486 ft-lbs of torque while maintaining a compact, serviceable package.
Every H Series drive includes two interchangeable, field-serviceable output shafts: a 2-inch hex shaft and a 2-9/16-inch round shaft. This dual-shaft design gives you the flexibility to run a broad range of auger bits without purchasing a separate drive.
Key Features
- Heavy-duty professional auger drive
- 10–20 GPM hydraulic-flow range
- Up to 2,486 ft-lbs of torque at 3,500 PSI
- Maximum speed of 86 RPM at 20 GPM
- Includes 2-inch hex and 2-9/16-inch round replaceable shafts
- Supports dirt augers up to 30 inches and rock augers up to 24 inches
- 6-year limited warranty
- Lifetime replacement coverage on the output shaft
Specifications
| Hydraulic Flow |
10–20 GPM |
| Continuous Pressure |
3,000 PSI |
| Intermittent Pressure |
3,500 PSI |
| Maximum Torque |
2,486 ft-lbs |
| Maximum Speed |
86 RPM at 20 GPM |
| Output Shafts |
2-inch hex and 2-9/16-inch round |
| Maximum Dirt Auger |
30 inches |
| Maximum Rock Auger |
24 inches |
| Drive Weight |
183 lbs |
| Kit Weight |
310 lbs |
Purchase Options
Drive Only: H-200 auger drive with both replaceable output shafts. Mounting kit and hydraulic hoses are not included.
Complete Kit: H-200 auger drive, QT100 universal skid-steer loader mount, 1/2-inch x 96-inch hydraulic hose kit, and both replaceable output shafts.
Auger bits are sold separately. Verify your machine's hydraulic flow, pressure, coupler requirements, and lift capacity before ordering.
Photos are generic for all of the H Series lineup.
